Air Service Subminiature 9 Pin C Type Cables£ 119 – £ 129 TECHNICAL SPECS – CLICK HERE Air Service Subminiature 9 Pin C Type Cables Connector to cable air-service round cable assemblies are fitted with a Delrin® subminiature C female connector at one end and non terminated nine PVC insulated wires on the other. The female cable connectors mate directly onto the air side of 9 pin subminiature C type feedthroughs. The cable jacket is grey PVC with a nominal diameter of 5.8mm. The 9 wires are 24AWG tinned copper conductors, stranded 7 x 0.203mm. Shielding is aluminium / Mylar® foil with 24AWG tinned copper drain wire. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Features: • 9 wire, 24AWG • Custom lengths available. Specifications: Voltage : Signal Current : Signal Material Conductors : Tinned 24AWG copper. Insulation : PVC Braid : Mylar® foil & tinned copper wire Temperature Range : -75°C to 80°C ______________________________________ Product CodeLength (mm)Cable TypeConnector TypePriceQuantityPDF & STP C9-AC1200 1200 9 x 7x0.2mmFemale £ 119 Add to quote STP C9-AC2000 2000 9 x 7x0.2mmFemale £ 129 Add to quote STP C9-AC2500 24009 x 7x0.2mmFemale £ 129 Add to quote STP SKU: N/A Category: Subminiature C
