Mil-C-26482 Circular 19 Pin Cables – UHV£ 307 – £ 395 TECHNICAL SPECS – CLICK HERE UHV Cable Assemblies Connector to cable UHV ribbon cable assemblies are fitted with female PEEK Mil-C-26482 type 19 pin connectors at one end and non-terminated Kapton® insulated ribbon cable at the other. The female connectors mate directly onto the vacuum side of the MIL-C-24682 feedthroughs. It is locked into place with a single captured retaining screw. The ribbon cable consists of 19 conductors with a PEEK monofilament outer weave. The indivividual conductors are 28AWG silver plated copper conductors, stranded 7 x 0.127mm with Kapton® insulation. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Features: • Mil-C-26482 type. • 19 pin configuration. • High temperature rated to 250°C. • Kapton® insulated in-vacuum cables. • PEEK connector with locking screws. Specifications: Voltage1 : 500VDC max Current1 : 5A max @ 20°C Material Cable : 28AWG silver plated copper conductors, stranded 7 x 0.127mm with Kapton® insulation. Pin : Gold plated Ni-Fe alloy In-vacuum connector3 : PEEK Temperature Range2 Vacuum side connector -200°C to 250°C Max. Thermal Gradient : 25°C / minute Kapton® Properties Dielectric constant : 2.9 Dielectric strength : 80kV/mm Dissipation factor, 1MHz : 0.002 Initial tear : 13.4kg/mm Elongation : 50% Moisture absorbtion : 0.4% @ 50% RH Radiation resistance : 109 Rads _________________________________________ 1 - Please see section introduction for safety information. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. 2 - Assembly rating is reduced to that of the lowest rated component. 3 - PEEK is a polyetheretherketone thermoplastic. Product CodeLengthCable TypeConnector TypePriceQuantityPDF & STP C19-VCF500 500 Ribbon Female £ 307 Add to quote STP C19-VCF1000 1000Ribbon Female £ 395 Add to quote STP C19-VCM500 500 RibbonMale £ 307 Add to quote STP C19-VCM1000 1000RibbonMale £ 395 Add to quote STP SKU: N/A Category: Circular Feedthroughs 19 Pin
