Mil-C-26482 Circular 19 Pin Cables & Connectors – Air Service

Mil-C-26482 Circular 19 Pin Cables & Connectors – Air Service£ 31 – £ 191 TECHNICAL SPECS – CLICK HERE Air-service Cable Assemblies & Connectors Connector to cable air-service round cable assemblies are fitted with an aluminium shell, with electroplated nickel finish, Mil-C-26482 19 pin female connector at one end. The cables are 24AWG  stranded tinned copper conductors. The non-terminated end has 20 colour coded PVC insulated wires. One wire is not connected to the Mil-C-26482 connector and is available for grounding or other purposes. The conductors are shielded with an aluminium polyester foil shield wrap and a 0.97mm grey PVC jacket. The cable is rated at 300V, 80°C and 24AWG. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Features: • Mil-C-26482 type. • 19 pin configuration. Specifications: Voltage1 : 300VDC max Current1 : 5A max @ 20°C Material Cable : 24AWG stranded tinned copper conductors. Temperature Range2 Vacuum side connector -200°C to 250°C PLEASE NOTE : Pins and sockets are sold in packs of 10 pieces, therefore 2 packs required to fully populate a 19 pin connector. _________________________________________ 1 - Please see section introduction for safety information. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. 2 - Assembly rating is reduced to that of the lowest rated component. Product CodeLengthCable TypeConnector TypePriceQuantityPDF & STP C19-AC1200 1200 19 x 7x0.2 Female straight £ 170 Add to quote STP C19-AC2500 2400 19 x 7x0.2 Female straight £ 191 Add to quote STP C19-AIR n/a n/a Female straight £ 74 Add to quote STP C19-AIR-90 n/a n/a Female 90° £ 101 Add to quote STP C19-APINF-10 n/a n/a Female pins 20-24AWG 10 pins per pack £ 31 Add to quote STP C19-APINM-10 n/a n/a Male pins 20-24AWG 10 pins per pack £ 31 Add to quote SKU: N/A Category: Circular Feedthroughs 19 Pin Related Products Select options Wiring Tools etc. Select options
