Subminiature D Type UHV Ribbon Cables – Female to Female Extension Cable
$14.08
$22.67
Subminiature D Type UHV Ribbon Cables – Female to Female Extension Cable£ 359 – £ 1,143 TECHNICAL SPECS – CLICK HERE Subminiature D Type UHV Ribbon Cables – Female to Female Extension Cable UHV Cable Assemblies Female connector to Female connector UHV ribbon extension cables are fitted with PEEK subminiature D Female connectors at both ends of the Kapton® insulated ribbon cable. The female cable connectors mate directly onto the vacuum side of subminiature D feedthroughs or with the male in-vacuum cable connectors. The ribbon cable is made with Kapton® insulated 28AWG silver plated copper conductors, stranded 7 x 0.127mm. The cables are woven with a PEEK monofilament with a nominal diameter of 0.2mm. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Features: • 7 x 0.127mm (28AWG) wires woven into a ribbon cable. • PEEK monofilament weave. • UHV compatible. • Custom lengths available. Specifications: Voltage : Signal Current : Signal Material Conductors : Silver plated copper. Insulation : Type F Kapton® film Braid / weave : PEEK In-vacuum connector2 : PEEK Temperature Range1 : -75°C to 250°C Kapton® Properties Dielectric constant : 2.9 Dielectric strength : 80kV/mm Dissipation factor, 1MHz : 0.002 Initial tear : 13.4kg/mm Elongation : 50% Moisture absorbtion : 0.4% @ 50% RH Radiation resistance : 109 Rads ______________________________________ 1 – Assembly rating is reduced to that of the lowest rated component. 2 – PEEK is a polyetheretherketone thermoplastic. Ceramic in vacuum connectors are also available, please contact sales office for details. Product CodeNo. ContactsLength (mm)Cable Dimension (mm)Connector TypeConnector Dims. WxHxDPriceQuantityPDF & STP D9R-2F500 9 500 1.02 x 10.2 Female 33.0 x 12.7 x 19.1 £ 359 Add to quote D9R-2F1000 9 10001.02 x 10.2 Female 33.0 x 12.7 x 19.1 £ 416 Add to quote D15R-2F500 15 500 1.02 x 18.8 Female 43.2 x 12.7 x 19.1 £ 468 Add to quote D15R-2F1000 15 1000 1.02 x 18.8 Female 43.2 x 12.7 x 19.1 £ 536 Add to quote D25R-2F500 25 500 1.02 x 30.5 Female 55.9 x 12.7 x 19.1 £ 582 Add to quote D25R-2F1000 25 1000 1.02 x 30.5 Female 55.9 x 12.7 x 19.1 £ 676 Add to quote D50R-2F500 50500 1.02 x 18.8 Female 68.6 x 12.7 x 19.1 £ 951 Add to quote D50R-2F1000 50 1000 2.03 x 30.5Female 68.6 x 12.7 x 19.1 £ 1,143 Add to quote SKU: N/A Category: Subminiature D
