Subminiature D Type UHV Ribbon Cables – Contact to Cable
$26.35
$46.9
Subminiature D Type UHV Ribbon Cables – Contact to Cable£ 79 – £ 499 TECHNICAL SPECS – CLICK HERE Subminiature D Type UHV Ribbon Cables – Contact to Cable UHV Cable Assemblies Contact to cable UHV ribbon cables are fitted with male or female contact pins at one end and non terminated, Kapton® insulated ribbon cable at the other. The ribbon cable is made with Kapton® insulated 28AWG silver plated copper conductors, stranded 7 x 0.127mm. The cables are woven with a PEEK monofilament with a nominal diameter of 0.2mm. Contact to cable UHV ribbon cables do not include PEEK connectors. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Special Note : The 50 pin contact fitted cable will not allow subsequent connector installation. Wires must be threaded through the 50 way connector back piece before crimping contacts. Features: • 7 x 0.127mm (28AWG) wires woven into a ribbon cable. • PEEK monofilament weave.• UHV compatible. • Custom lengths available. Specifications: Voltage : Signal Current : Signal Material Conductors : Silver plated copper. Insulation : Type F Kapton® film Braid / weave : PEEK Temperature Range1 : -75°C to 250°C Kapton® Properties Dielectric constant : 2.9 Dielectric strength : 80kV/mm Dissipation factor, 1MHz : 0.002 Initial tear : 13.4kg/mm Elongation : 50% Moisture absorbtion : 0.4% @ 50% RH Radiation resistance : 109 Rads ______________________________________ 1 – Assembly rating is reduced to that of the lowest rated component. 2 – PEEK is a polyetheretherketone thermoplastic. Ceramic in vacuum connectors are also available, please contact sales office for details. Product CodeNo. ContactsLength (mm)Cable Dimension (mm)Connector TypeSocket / PinPriceQuantityPDF & STP D9RL-F500 9 500 1.02 x 10.2 Female Socket £ 79 Add to quote D9RL-F1000 9 10001.02 x 10.2 Female Socket £ 130 Add to quote D9RL-M500 9 500 1.02 x 10.2 Male Pin £ 79 Add to quote D9RL-M1000 9 10001.02 x 10.2 Male Pin £ 130 Add to quote D15RL-F500 15 500 1.02 x 18.8 Female Socket £ 105 Add to quote D15RL-F1000 15 1000 1.02 x 18.8 Female Socket £ 177 Add to quote D15RL-M500 15 500 1.02 x 18.8 Male Pin £ 105 Add to quote D15RL-M1000 15 1000 1.02 x 18.8 Male Pin £ 177 Add to quote D25RL-F500 25 500 1.02 x 30.5 Female Socket £ 156 Add to quote D25RL-F1000 25 1000 1.02 x 30.5 Female Socket £ 249 Add to quote D25RL-M500 25 500 1.02 x 30.5 Male Pin £ 156 Add to quote D25RL-M1000 25 1000 1.02 x 30.5 Male Pin £ 249 Add to quote D50RL-F500 50500 2.03 x 30.5Female Socket £ 307 Add to quote D50RL-F1000 50 1000 2.03 x 30.5Female Socket £ 499 Add to quote D50RL-M500 50500 2.03 x 30.5 Male Pin £ 307 Add to quote D50RL-M1000 50 1000 2.03 x 30.5 Male Pin £ 499 Add to quote SKU: N/A Category: Subminiature D
