Subminiature D Type Stainless Steel Backshell Strain Relief
$43.6
$74.56
Subminiature D Type Stainless Steel Backshell Strain Relief£ 146 – £ 235 TECHNICAL SPECS – CLICK HERE Subminiature D Type Stainless Steel Backshell Strain Relief Backshell strain relief for Subminiature D type connectors suitable for use in UHV environments with MACOR D connectors. Connector,Contact sockets & pins must be ordered separately. Features: • UHV compatible. Specifications: Voltage : Signal Current : Signal Material2 : PEEK Temperature Range1 : -75°C to 250°C ______________________________________ 1 – Assembly rating is reduced to that of the lowest rated component. 2 – PEEK is a polyetheretherketone thermoplastic. Ceramic in vacuum connectors are also available, please contact sales office for details. Product CodeNo. ContactsDimensions w x d x h (mm)Use With Connector PartPriceQuantityPDF & STP D9SSSR 9 25.4 x 16.5 x 31.8 D9-CONF-MAC / D9-CONM-MAC £ 146 Add to quote STP D15SSSR 15 33.0 x 16.5 x 31.8 D15-CONF-MAC / D15-CONM-MAC £ 167 Add to quote STP D25SSSR 25 48.3 x 16.5 x 46.5 D25-CONF-MAC / D25-CONM-MAC £ 188 Add to quote STP D50SSSR 50 59.7 x 16.5 x 46.5 D50-CONF-MAC / D50-CONM-MAC £ 235 Add to quote STP SKU: N/A Category: Subminiature D
