Subminiature D Type HV Ribbon Cables – Contact to Cable
$29.52
$55.2
Subminiature D Type HV Ribbon Cables – Contact to Cable£ 43 – £ 382 TECHNICAL SPECS – CLICK HERE Subminiature D Type HV Ribbon Cables – Contact to Cable HV Cable Assemblies Contact to cable HV ribbon cables are fitted with male or female contact pins at one end and non terminated, FEP Teflon® insulated ribbon cable at the other. These components are suitable for vacuum applications down to 1 x 10-8 Torr with a maximum temperature of 125°C. The ribbon cable jacket is an extruded FEP Teflon®, the conductor is 28AWG silver plated copper, stranded 7 x 0.127mm. Contact to cable UHV ribbon cables do not include connectors. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Special Note : The 50 pin contact fitted cable will not allow subsequent connector installation. Wires must be threaded through the 50 way connector back piece before crimping contacts. Features: • 7 x 0.127mm (28AWG) wires. • HV compatible. • Custom lengths available. Specifications: Voltage : Signal Current : Signal Material Conductors : Silver plated copper. Insulation : FEP Tefloon® Temperature Range1 : -75°C to 125°C ______________________________________ 1 – Assembly rating is reduced to that of the lowest rated component. 2 – PEEK is a polyetheretherketone thermoplastic. Product CodeNo. ContactsLength (mm)Cable Dimension (mm)Connector TypeSocket / PinPriceQuantityPDF & STP D9HVRL-F500 9 500 0.76 x 11.4 Female Socket £ 43 Add to quote D9HVRL-F1000 9 10000.76 x 11.4 Female Socket £ 81 Add to quote D9HVRL-M500 9 500 0.76 x 11.4 Male Pin £ 52 Add to quote D9HVRL-M1000 9 10000.76 x 11.4 Male Pin £ 81 Add to quote D15HVRL-F500 15 500 0.76 x 19.1 Female Socket £ 81 Add to quote D15HVRL-F1000 15 1000 0.76 x 19.1 Female Socket £ 118 Add to quote D15HVRL-M500 15 500 0.76 x 19.1 Male Pin £ 81 Add to quote D15HVRL-M1000 15 1000 0.76 x 19.1 Male Pin £ 118 Add to quote D25HVRL-F500 25 500 0.76 x 31.8 Female Socket £ 130 Add to quote D25HVRL-F1000 25 1000 0.76 x 31.8 Female Socket £ 192 Add to quote D25HVRL-M500 25 500 0.76 x 31.8 Male Pin £ 130 Add to quote D25HVRL-M1000 25 1000 0.76 x 31.8 Male Pin £ 192 Add to quote D50HVRL-F500 50500 1.52 x 31.8Female Socket £ 261 Add to quote D50HVRL-F1000 50 1000 1.52 x 31.8Female Socket £ 382 Add to quote D50HVRL-M500 50500 1.52 x 31.8 Male Pin £ 261 Add to quote D50HVRL-M1000 50 1000 1.52 x 31.8 Male Pin £ 382 Add to quote SKU: N/A Category: Subminiature D
