Subminiature D Type HV Connectors£ 47 – £ 105 TECHNICAL SPECS – CLICK HERE Subminiature D Type HV Connectors Subminiature D type connectors suitable for use in HV environments. Contact sockets & pins must be ordered separately. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Features: • HV compatible. Specifications: Voltage : Signal Current : Signal Material2 : Stainless steel / DAP Temperature Range1 : -75°C to 250°C ______________________________________ 1 – Assembly rating is reduced to that of the lowest rated component. 2 – DAP is a glass filled dyiathilate. Product CodeNo. ContactsConnector Dimension (mm)Use ContactPriceQuantityPDF & STP D9-HVCONF 9 31.0 x 12.7 x 15.5 DPINHVF-25 £ 67 Add to quote STP D15-HVCONF 15 39.4 x 12.7 x 15.5 DPINHVF-25 £ 71 Add to quote STP D25-HVCONF 25 53.3x 12.7 x 15.5 DPINHVF-25 £ 73 Add to quote STP D50-HVCONF 50 67.3 x 12.7 x 15.51DPINHVF-25 £ 105 Add to quote STP D9-HVCONM 9 31.0 x 12.7 x 15.5 DPINHVM-25 £ 47 Add to quote STP D15-HVCONM 15 39.4 x 12.7 x 15.5 DPINHVM-25 £ 50 Add to quote STP D25-HVCONM 25 53.3x 12.7 x 15.5 DPINHVM-25 £ 62 Add to quote STP D50-HVCONM 50 67.3 x 12.7 x 15.51 DPINHVM-25 £ 88 Add to quote SKU: N/A Category: Subminiature D Related Products Select options Wiring Tools etc. Select options Select options Pins & Sockets for C & D Connectors Select options Select options Subminiature D Type HV Backshell Strain Relief Select options
