Subminiature D Type HV Backshell Strain Relief£ 32 – £ 48 TECHNICAL SPECS – CLICK HERE Subminiature D Type HV Backshell Strain Relief Nickel-plated zinc back shell strain relief for HV connectors. Note: NOT recommended for use with flat ribbon cable or small diameter wire. Use with small diameter wire may require use of additional wire protection such as FEP or PTFE heat shrink tubing to help protect the wire from damage. PLEASE NOTE : These are machined after Nickel plating to allow them to mate with in vacuum feedthroughs, this means there is a small area on zinc exposed to your vacuum. Connector,Contact sockets & pins must be ordered separately. Product CodeNo. ContactsDimensions With Connector w x d x h (mm)Use With Connector PartPriceQuantityPDF & STP D9-HVSR 9 49.5 x 16.5 x 31.0 D9-HVCONF / D9-HVCONM £ 32 Add to quote STP D15-HVSR 15 43.8 x 16.1 x 40.1 D15-HVCONF / D15-HVCONM £ 37 Add to quote STP D25-HVSR 25 43.8 x 16.1 x 53.3 D25-HVCONF / D25-HVCONM £ 41 Add to quote STP D50-HVSR 50 44.5 x 23.5 x 67.18 D50-HVCONF / D50-HVCONM £ 48 Add to quote STP SKU: N/A Category: Subminiature D
