Subminiature D Type Air Side Cables & Connectors etc.

Subminiature D Type Air Side Cables & Connectors etc.£ 12 – £ 274 TECHNICAL SPECS – CLICK HERE Subminiature D Type Air Side Cables & Connectors etc. Air service cable assemblies are 3m (10 feet) long and terminated with industry standard moulded male / female subminiature D connectors. These cables have straight through pin-to-pin wiring. 26AWG wires, 300V max, 80°C max. Please contact our sales office for special cable assembly configurations. Air service connectors accept up to 20AWG wires. Contacts are gold plated and the shell has a tin finish. Plastic subminiature D hoods are a one piece, unshielded design with long knurled thumb screws, a side snaplock and a metal screw down strain relief. Gender changers are offered for use with LewVac subminiature D feedthroughs with male pins on both sides, to correct pin numbering to the standard subminiature D configuration. Pin 1 reverses position from vacuum side to air side due to the male-to-male configuration. Air service gender changers are made with Delrin® material. Stated electrical ratings are maximum test values. Feedthroughs are intended for instrumentation applications carrying low level signal voltages and currents. For proper heat dissipation a maximum of 20% of the pins on a feedthrough may carry the maximum current at any one time. Product CodeDescriptionPriceQuantityPDF & STP D9-AIRCAB-3M D9 AIR SIDE CABLE FEMALE TO MALE 3m £ 36 Add to quote D15-AIRCAB-3M D15 AIR SIDE CABLE FEMALE TO MALE 3m £ 47 Add to quote D25-AIRCAB-3M D25 AIR SIDE CABLE FEMALE TO MALE 3m £ 57 Add to quote D50-AIRCAB-3M D50 AIR SIDE CABLE FEMALE TO MALE 3m £ 108 Add to quote D9-AC D9 AIR SIDE CONNECTOR - SOLDER BUCKET £ 12 Add to quote D15-AC D15 AIR SIDE CONNECTOR - SOLDER BUCKET £ 14 Add to quote D25-AC D25 AIR SIDE CONNECTOR - SOLDER BUCKET £ 16 Add to quote STP D50-AC D50 AIR SIDE CONNECTOR - SOLDER BUCKET £ 27 Add to quote STP D9-GA D9 GENDER CHANGER FOR AIR SIDE USE £ 119 Add to quote D15-GA D15 GENDER CHANGER FOR AIR SIDE USE £ 141 Add to quote D25-GA D25 GENDER CHANGER FOR AIR SIDE USE £ 155 Add to quote D50-GA D50 GENDER CHANGER FOR AIR SIDE USE £ 274 Add to quote D9-GA-MM D9 GENDER CHANGER M/M FOR AIR SIDE USE £ 134 Add to quote STP D15-GA-MM D15 GENDER CHANGER M/M FOR AIR SIDE USE £ 155 Add to quote STP D25-GA-MM D25 GENDER CHANGER M/M FOR AIR SIDE USE £ 166 Add to quote STP D50-GA-MM D50 GENDER CHANGER M/M FOR AIR SIDE USE £ 274 Add to quote STP SKU: N/A Category: Subminiature D
