Mil-C-5015 In Vacuum Circular Cables£ 157 – £ 416 TECHNICAL SPECS – CLICK HERE Mil-C-5015 In Vacuum Circular Cables Connector to cable UHV cable assemblies are fitted with female Mil-C-5015 type PEEK 3 pin or 6 pin connectors at one end and either 3 or 6, non-terminated Kapton® insulated wires at the other. The female cable connectors mate directly onto the vacuum side of Mil-C-5015 feedthroughs shown on the previous page. The individual conductors are 18AWG, 10A silver plated copper wire, stranded 19 x 0.23mm, with Kapton® insulation. When assembling connectors, the wires must be threaded through the back part of the connector before contacts are crimped in place. Product CodeCable LengthCable DiameterConnector TypeConnector Dims.PriceQuantityPDF & STP C3-VCF500 500 3 x 1.52 Female 15.8 x 27.9 £ 157 Add to quote C3-VCF1000 10003 x 1.52 Female 15.8 x 27.9 £ 184 Add to quote C3-VCM500 500 3 x 1.52 Male 15.8 x 25.9 £ 157 Add to quote C3-VCM1000 10003 x 1.52 Male 15.8 x 25.9 £ 184 Add to quote C6-VCF500 500 6 x 1.52Female 22.2 x 27.9 £ 212 Add to quote C6-VCF1000 1000 6 x 1.52Female 22.2 x 27.9 £ 265 Add to quote C6-VCM500 500 6 x 1.52 Male 22.2 x 25.9 £ 212 Add to quote C6-VCM1000 1000 6 x 1.52 Male 22.2 x 25.9 £ 265 Add to quote C3-EVCFF500 500 3 x 1.52 2 x Female15.8 x 27.9 £ 191 Add to quote C3-EVCFF1000 10003 x 1.52 2 x Female15.8 x 27.9 £ 297 Add to quote C6-EVCFF500 500 6 x 1.52 2 x Female 22.2 x 25.9 £ 357 Add to quote C6-EVCFF1000 1000 6 x 1.52 2 x Female 22.2 x 25.9 £ 416 Add to quote SKU: N/A Category: Multipin power
